Rigid rail Light KBK Crane System

INQUIRY

Introduction:
Rigid crane system is kind of Truss light duty suspension crane system. It is more ergonomic and cost effective solutions comparing to traditional suspension crane system, especially in applications that height and space are limited. Modular design, can achieve multi-functional diversified and safe &reliable hanging conveyor program in a large number of practical applications. Complete design crane solution as per customer actual requirements.

Advantage:
1. Max span 10 meters
2. Enclosed rail design
3. Rigid connection, stable and precise positioning.
4. Rail cold rolling forming, no welding, high strength
5. Different installation method as your optional
6. Manual & Electric as your optional

Difference between flexible and rigid crane system

Item	Rigid Crane	Flexible crane
Load capacity	Max 2000kg	Max 3000kg
Connection method	Rigid connection (compact & stable)	Suspension device (flexible)
Span	Max 10m	Max 8.5m (single girder)
End carriage	Yes	No
Rail	Truss type	Monorail
Application	Limited space	/

Technical Parameter:

Load	Rail No	L4 (mm)	L1(mm)	L2(mm)	L5(mm)	L6(mm)
250kg	I-N	2500	1900	1200	600	1200
250kg	I-N	10000	9000
500kg	II-N	2500	1800
500kg	II-H	10000	9000
1000kg	III-H	3000	2000
1000kg	III-H	10000	9000
2000kg	III-H	9000	8000

Load capacity: 125~2000kg
Material: Steel
Mode of operation: manual/electric
Working class: A3
Installation method: suspension/hanging/self support
Application place: Workshop/warehouse/Assembly shop/Car factory/Auto shop,etc
